Please Note: Minimum Breaking Strength (MBS) is the minimum force necessary to cause a recovery device to break or fail. Working Load Limit (WLL) is the recommended maximum force a recovery device is intended to support safely when the force is applied in-line and through the centerline of the device. The WLL is calculated by dividing the Minimum Breaking Strength (MBS) by a safety factor around 4-to-1.
For example, the AEV Snatch Block (AEV80808011AA) has an MBS of 52,000 LBS, so when divided by a safety factor of 4-to-1, the WLL becomes 13,000 LBS.
Material:
- Dyneema® SK78 w/ dual layer chafe protection
Color:
- Black w/ Red Ends
Installation Difficulty Level:
- Easy
Manufactured In: Canada
Dimensions:
Length: 10 ft
Diameter: 3/8 in
Minimum Breaking Strength (MBS)
- 19,600 LBS (8,890 KG)
Working Load Limit (WLL)
- 4,900 LBS (2,222 KG)
